30 Different Types of Woven Fabric with Pictures

You know that moment when you’re holding a beautiful piece of fabric, ready to cut into it—only to realize halfway through sewing that it’s slipping, puckering, or just refusing to behave? Yeah, we’ve all been there. It’s not always the machine or your technique; sometimes, it’s simply that you didn’t fully understand what kind of woven fabric you were working with. And honestly, even experienced designers get tripped up by subtle differences in weave structure, fiber content, and finishing.

Let’s fix that. Below is a deep dive into 30 different types of woven fabrics—complete with real-world insights, technical nuances, and practical tips from years of trial, error, and (occasionally) triumph in garment construction and textile selection. Whether you’re choosing materials for a client’s bespoke jacket or sourcing sustainable options for a small batch run, this guide will help you make smarter decisions—not just based on how a fabric looks, but on how it works.

What is Woven Fabric?

Woven fabric is any textile formed by interlacing warp (lengthwise) and weft (crosswise) threads at right angles using a loom. Unlike knits, which stretch and loop, wovens rely on structural integrity built through tight intersections. That makes them generally more stable, less elastic, and better suited for structured garments like blazers, coats, trousers, and upholstery.

But here’s the thing: not all wovens are created equal. A lightweight chiffon behaves nothing like a heavy-duty denim, even though both are technically “woven.” The difference lies in three core elements:

Weave type (plain, twill, satin)
Fiber composition (cotton, silk, polyester, etc.)
Finishing processes (singeing, mercerizing, calendaring, coating)

These factors affect everything—from drape and durability to shrinkage and seam strength. For example, a tightly woven cotton poplin might resist fraying well during construction, while an open-weave muslin can unravel after one careless snip. Understanding these subtleties helps prevent costly mistakes down the line.

One note: if you’re sourcing fabric commercially, pay attention to GSM (grams per square meter). It gives you a quick sense of weight. Lightweights hover around 60–100 GSM (like voile), midweights range from 120–200 GSM (drill, gabardine), and heavies go above 250 GSM (canvas, corduroy). I keep a little reference card taped inside my design notebook because, yes, I still forget sometimes.

Now let’s break down the most common—and some not-so-common—types of woven fabrics used across fashion, home textiles, and accessories.

Leno Fabric

Also known as gauze weave, leno fabric uses a special weaving technique where two warp threads cross over each other between every weft insertion. This creates a stable, open-lattice structure that prevents the filling yarns from shifting—a huge advantage when working with sheer or loosely constructed fabrics.

This interlocking mechanism is achieved using doup heddles, which allow precise control over individual thread pairs. The result? Fabrics that maintain openness without sacrificing stability. Think of it like building a fence with interwoven pickets instead of nailed ones—stronger against lateral movement.

Professionally, I’ve used leno weaves in summer scarves and bridal overlays where airflow matters. But be careful: because of its openness, raw edges will fray quickly unless finished with a rolled hem or lace trim. Use a fine needle—size 60/8 or 70/10—and low tension to avoid distorting the delicate structure.

A micro-note: Pura Fabric once sourced a silk-lenyo blend for a resort collection. We loved the drape, but discovered post-wash that the silk shrank slightly more than the synthetic component. Lesson learned: always pre-shrink test blends, especially those with protein fibers.

Crepe

Crepe isn’t a fiber—it’s a texture. Specifically, it refers to fabrics made with highly twisted yarns that create a pebbled, crinkled surface. These twists contract unevenly during washing or heat setting, giving crepe its signature matte finish and resistance to wrinkling.

There are dozens of subtypes: crepe de chine (silk, soft), georgette (polyester or silk, rougher), wool crepe (excellent recovery), and sandpaper crepe (literally feels like fine grit). Most have moderate stretch across the bias, making them forgiving on the body—but tricky on the cutting table.

When sewing crepe, stabilize seams with tissue paper underneath. Why? Because the fabric grabs the feed dogs unevenly due to its textured surface. I once ruined a sleeve cap by skipping this step—ended up with wavy gathers where smooth shaping should’ve been.

For pressing: use a press cloth and minimal steam. Too much moisture can flatten the crinkle permanently. If you need to restore texture, hang the garment in a steamy bathroom overnight. Works like magic.

Case Study: A client wanted a flowy midi dress in black polyester crepe. Off-the-rack versions kept clinging to her hips. After draping three iterations, we switched to a heavier 145 GSM version with more body. Result? Clean drape, no cling. Sometimes, weight matters more than fiber.

Drill Fabric

Drill is a sturdy, warp-faced twill fabric—meaning the warp threads dominate the surface. It typically follows a 3/1 or 4/1 diagonal pattern, creating a strong, durable cloth often used in workwear, military uniforms, and utility jackets.

Cotton drill averages around 220–280 GSM, depending on end use. Army surplus jackets often use 260+ GSM for abrasion resistance. For tailored pants, aim for 200–240 GSM—enough structure without stiffness.

Sewing tip: because drill has noticeable diagonal lines, pattern alignment is critical. Misaligned pockets or belt loops scream amateur hour. Always mark the grainline clearly before cutting.

Needle choice: universal 90/14 works well. If using a coated or water-resistant version, consider a jeans needle (100/16) to pierce without damaging the finish.

Fun fact: safari suits were originally made from beige cotton drill because it resisted dirt and held shape under harsh conditions. Still true today—if you want functional elegance, drill delivers.

Denim

Denim is a left-hand twill weave, usually cotton-based, where the warp is dyed indigo and the weft remains white. That’s why the back side looks lighter. Authentic denim fades uniquely over time because only the surface fibers wear away, revealing the undyed core beneath.

Weight varies widely:

Light: 9–11 oz/yd² (~300–370 GSM) – great for shirts
Mid: 12–14 oz (~400–470 GSM) – standard jeans
Heavy: 15+ oz (~500+ GSM) – jackets, aprons

I prefer 13.5 oz selvage denim for custom jeans. It molds to the wearer without being overly stiff. But heavy denim? Brutal to sew unless you upgrade your machine. I blew a bobbin case once trying to stitch through triple layers at the fly.

Use topstitching thread (Tex 40 or 60) and a saddle needle (110/18) for visible seams. Set stitch length to 3.5 mm for durability. And never skip pre-washing—raw denim can shrink up to 10% in length.

Micro-note: Some eco-brands now offer laser-finished denim to reduce water usage. The mill we worked with last year cut processing water by 90%. Worth considering if sustainability is part of your brand ethos.

Flannel

Flannel is brushed on one or both sides to raise the fibers, creating a soft, fuzzy surface. Traditionally wool, modern flannel is mostly cotton or cotton-poly blends. Ideal for pajamas, shirts, and baby clothes thanks to its warmth and comfort.

But brushing compromises strength. Brushed fabrics lose up to 15% of tensile strength compared to their unbrushed counterparts. So reinforce stress points—shoulders, cuffs, plackets—with stay tape or interfacing.

GSM ranges from 160 (light shirt flannel) to 220 (winter-weight). Higher GSM means more loft, but also more bulk at seams. When sewing collars or cuffs, trim seam allowances and grade corners to reduce lumps.

Press gently. Too much heat flattens the nap. Always press on the wrong side, or use a pressing mitt if you must touch the face.

Personal quirk: I hate sewing flannel. It shifts, pills, and sheds lint everywhere. But people love wearing it. So I do it anyway—usually with extra pins and lots of patience.

Chiffon

Chiffon is sheer, floaty, and notoriously difficult to handle. Made from tightly twisted filament yarns (silk, nylon, or polyester), it has a slight grip that causes it to cling to itself and tools.

Most chiffons fall between 6–10 mm in thickness and weigh 30–50 GSM. Despite being light, they require careful handling because of poor tear strength.

Cutting? Use weights instead of pins. Pins leave holes that don’t close. And layer tissue paper beneath when sewing—otherwise, the feed dogs will eat it alive.

French seams are essential. They enclose raw edges and prevent fraying. Stitch first at 1.5 mm, then turn and stitch again at 3 mm. Yes, it takes longer. No, there’s no good shortcut.

A designer friend once used metallic-coated chiffon for a runway piece. Gorgeous—but it shredded under studio lights within two hours. Moral: beauty doesn’t always equal wearability.

Casement

Casement fabric is a tightly woven, medium-weight cotton designed for curtains and window treatments. Thick warp yarns are packed closely together, blocking light and adding structure.

It’s rarely used in apparel due to its stiffness and lack of drape. However, I’ve seen avant-garde designers repurpose it for sculptural silhouettes—think architectural coats or statement sleeves.

Because it resists stretching, it’s excellent for roman shades or valances. Finish edges with binding or double-fold hems to prevent fraying.

If attempting garment use, pre-wash thoroughly. Untreated casement can shrink dramatically—up to 8% in hot water.

Georgette

Georgette is a heavier cousin of chiffon, made with hard-twisted yarns in both warp and weft. The twist creates a crinkled texture and reduces transparency.

Polyester georgette dominates the market—it’s affordable, colorfast, and holds pleats well. Silk versions exist but cost significantly more and demand dry cleaning.

Ideal for evening wear, hijabs, and layered skirts. Drape is fluid but not clingy, thanks to its slight stiffness.

Sewing challenge: slippery + sheer = nightmare combo. Use silk pins or fine glass-head pins so they glide in cleanly. And baste, baste, baste.

One project went sideways when I tried flat-felling seams on a georgette blouse. Created massive ridges. Switched to narrow French seams—much better.

Lawn Fabric

Lawn is a finely woven, crisp cotton fabric with a high thread count—often 180–200 TC or higher. Originally made from combed cotton, it has a smooth hand and slight sheen.

Popular for summer shirts, blouses, and children’s dresses. Crispness comes from starch-like finishes, which wash out over time. Want lasting stiffness? Look for “permanent finish” labels.

Ironing: use high heat and steam. Starch optional, but recommended for formal wear.

Avoid tumble drying—high heat damages cellulose fibers and accelerates pilling.

Wool

Wool is a natural protein fiber from sheep, known for insulation, resilience, and wrinkle recovery. Not all wool is scratchy—finer varieties like merino feel soft against the skin.

Woven wool fabrics vary widely:

Tropical wool (lightweight, breathable)
Flannel (brushed, cozy)
Gabardine (tightly woven, weather-resistant)

Shrinkage is a real issue. Machine washing can felt wool irreversibly. Always recommend dry cleaning—or hand wash in cool water with pH-neutral detergent.

Press with a damp cloth and plenty of steam. Wool responds beautifully to heat shaping. Lapels, shoulders, and darts benefit from controlled pressing.

Pura Fabric recently developed a blended tropical wool with TENCEL™ for breathability. Clients loved the drape, though it required adjusting seam allowances—natural fibers shifted slightly during construction.

Polyester

Synthetic, strong, and stubborn. Polyester resists wrinkles, shrinking, and stretching. But it traps heat and doesn’t absorb moisture—so it’s great for performance outerwear, less ideal for next-to-skin layers.

Weave determines function:

Plain weave: shirting
Twill: suiting
Knit: activewear

Melting point is around 250°C (482°F)—so use low heat when pressing. A cotton pressing cloth is mandatory. Burn marks are permanent.

Pilling happens when short fibers migrate to the surface and tangle. To reduce it, choose high-twist yarns or anti-pilling finishes.

Honestly? I avoid 100% polyester unless necessary. But blends—especially with cotton or wool—are underrated. They add durability without killing drape.

Cheese Cloth

An ultra-open plain weave, cheese cloth is gauzy and fragile. Originally for straining dairy, now used in theater costumes, medical wraps, and experimental fashion.

Grade 10 (loosest) to Grade 90 (tightest). Most apparel uses Grade 60–70.

Because it frays instantly, finish every edge immediately. Zigzag stitch or bound hems work best.

Great for layering—six plies still feel light. But don’t expect longevity. One costume piece lasted three fittings before tearing at the shoulder.

Chintz Fabric

Chintz is a glazed cotton fabric, often printed with floral motifs. The shine comes from calendering—passing the fabric through heated rollers under pressure.

Glaze wears off with washing. Semi-permanent versions last 3–5 washes. For longer life, suggest spot cleaning or gentle hand wash.

Use a walking foot when sewing. The slick surface slides easily. And avoid high heat—glaze can melt or crack.

Lace

Lace is not technically woven—it’s either knitted, crocheted, or embroidered. But it’s often incorporated into woven garments, so it belongs here.

Two components: motif and net ground. Quality depends on uniformity, density, and attachment strength.

When applying lace to garments:

Cut with small scissors or rotary cutter
Hand-baste first
Use a straight-stitch needle plate to prevent snagging

Delicate laces need protection. Consider lining sheer panels or reinforcing attachment points with clear elastic.

Velvet

Velvet is a pile fabric with cut ends standing upright. The direction of the pile (the “nap”) affects color and texture—always cut all pieces in the same direction.

Compresses under pressure. Store flat or rolled, never folded sharply.

Seam challenges: pile crushes at seam lines. Solution? Slash pile depth along seam allowances before folding them open.

Use a velvet-specific needle (ballpoint with cut tip) or a microtex 70/10. Press with a velvet board or on a towel to protect the pile.

Nylon

Nylon is strong, elastic, and water-resistant. Common in outerwear, linings, and sportswear.

Melts at ~215°C. Press carefully. Use lowest iron setting with press cloth.

Resists UV degradation better than polyester. Good for outdoor gear.

But it builds static. Anti-static sprays or dryer sheets help.

Silk

Luxurious, strong, and temperamental. Silk is the strongest natural fiber—until it gets wet. Wet silk loses up to 20% of its strength.

Always pre-wash in cool water with silk shampoo. Never wring. Roll in a towel to remove excess moisture.

Bias cuts drape like liquid. But bias edges stretch. Stay-stitch immediately after cutting.

One couture project used raw silk for a draped gown. Gorgeous—but shed fibers clogged our machines daily. We cleaned them twice a day. Worth it? For the client, yes.

Satin

Satin refers to a weave structure (typically 4/1), not a fiber. Can be silk, polyester, acetate, or cotton.

Smooth, glossy face; dull back. Slips easily—use clips instead of pins.

Fraying is severe. Finish edges quickly.

Avoid sharp objects. Snags are nearly impossible to repair.

Twill

Defined by diagonal ribs, twill weaves are durable and hide soil well. Denim, gabardine, and drill are all twills.

The diagonal allows flexibility while maintaining strength. Great for pants and jackets.

Press along the bias of the rib, not across it. Prevents flattening the texture.

Herringbone

A variation of twill with a broken zigzag pattern. Visually dynamic, structurally sound.

Common in wool suiting. Adds texture without bulk.

Pattern matching matters. Align chevrons precisely at seams—especially center backs and plackets.

Muslin

Lightweight, plain-weave cotton. Used for toiles (mockups), summer clothing, and basic linings.

Unbleached muslin costs less and behaves more predictably than cheap fashion fabrics.

When making a prototype, I always use muslin first. Saved me from cutting into $40/sq yard silk more times than I can count.

Corduroy

Corduroy has vertical wales (ribs) formed by cut pile. Measured by wales per inch (WPI):

Broadcord: 4–6 WPI
Pinwale: 12+ WPI

Higher WPI = finer ribs.

Cut all pieces in the same direction. Reversing nap changes color.

Trim wales in seam allowances to reduce bulk.

Gabardine

Tightly woven 2/2 twill with a steep diagonal. Weather-resistant and crisp.

Used in trench coats, suits, and uniforms.

High abrasion resistance. Ideal for travel wear.

Pre-shrink before cutting—can shrink 3–5%.

Buckram Fabric

Stiff, open-weave fabric coated with starch or plastic. Used in hat-making and collar interfacing.

Available in varying stiffness levels. Choose based on desired structure.

Can yellow over time. Avoid direct sunlight.

Cambric Fabric

Fine, tightly woven cotton with a smooth finish. Similar to lawn but slightly heavier.

Common in shirt collars and cuffs.

Resists pilling better than standard cotton broadcloth.

Taffeta

Crisp, rustling fabric with a slight rib. Originally silk, now often polyester.

Popular in wedding gowns and linings.

Noise level: high. Not ideal for quiet environments.

Fraying is aggressive. Finish edges with Hong Kong or binding.

Kashmir Silk

Luxurious silk from Kashmir, often hand-embroidered with traditional motifs like paisleys and florals.

Typically woven in plain or twill weave.

Handle with care. Embroidery threads can snap under tension.

Dry clean only.

Khadi

Hand-spun, hand-woven fabric from India. Often cotton, but blends exist.

Textured, rustic appearance. Each bolt varies slightly—part of the charm.

Pre-wash aggressively. Can shrink 8–10%.

Embrace imperfections. That’s the point.

Sheeting Fabric

Medium-weight, tightly woven fabric for bed sheets. Usually cotton or polycotton.

Weave: plain or sateen.

Thread count indicates quality—200 TC minimum for decent bedding.

Durability tested via Martindale rub tests (aim for 15,000+ for commercial use).

Net

Open mesh fabric with knotted or fused intersections. Used in veils, tutus, and overlays.

Types: tulle, bobbinet, hex net.

Stretch varies. Test before cutting.

Supports embellishments well—beads, sequins, embroidery.

Cotton

The most widely used natural fiber. Breathable, comfortable, versatile.

Ginning separates fiber from seed. Then spun and woven.

Blends enhance performance: cotton-poly resists wrinkles; cotton-elastane adds stretch.

Prone to shrinkage (up to 5%) and wrinkling. Pre-wash and starch for crispness.

Yields many derivatives: chino, muslin, gingham, denim.

Final Thought

Choosing the right woven fabric isn’t just about aesthetics. It’s about understanding how fiber, weave, weight, and finish interact during construction and throughout the garment’s life. I’ve ruined expensive yards of material just because I ignored pre-treatment or misjudged drape. You will too—until you don’t. Keep swatching, testing, and asking questions. The fabric knows what it wants to be; your job is to listen.
